MSI 880GMA-E45 series

2-2
Hardware Setup
MS-7623
Chapter 2
Hardware Setup
MS-7623
Chapter 2
Quick Components Guide
CPU, p.2-3
DDR3, p.2-6
Back Panel,
p.2-9
CPUFAN, p.2-13
JLPT1, p.2-16
JCI1, p.2-13
JCOM1, p.2-16
FDD1, p.2-11
IDE1, p.2-11
JPWR1, p.2-8
SYSFAN1, p.2-13
SATA1~6, p.2-12
JFP1, JFP2, p.2-12
JBAT1, p.2-18
JUSB1~4, p.2-14
JTPM1, p.2-15
OC_SW1, p.2-17
JSP1, p.2-15
JCD1, p.2-13
JAUD1, p.2-14
PCI, p.2-19
PCIE, p.2-19
JPWR2, p.2-8
SYSFAN2, p.2-13
