MSI 880GMA-E45 series

2-12
Hardware Setup
MS-7623
Chapter 2
Hardware Setup
MS-7623
Chapter 2
Serial ATA Connector: SATA1~6
This connector is a high-speed Serial ATA interface port. Each connector can connect
to one Serial ATA device.
* The MB layout in this 󰘰gure is for reference only.
Important
Please do not fold the Serial ATA cable into 90-degree angle. Otherwise, data loss
may occur during transmission.
Front Panel Connector: JFP1, JFP2
This connector is for electrical connection to the front panel switches and LEDs. The
JFP1 is compliant with Intel
®
Front Panel I/O Connectivity Design Guide.
1.+
3.
-
10.No
Pi
n
5.
-
Reset
S
witch
HDD
LE
D
P
ower
S
witch
P
ower
LE
D
7.
+
9.Reserve
d
8.
-
6.
+
4.
-
2.
+
JFP1
1
.Ground
3.Suspend
LE
D
5.Power
LE
D
7.No
Pi
n
8.
+
6.
-
4.
+
2.
-
Buzzer
S
peaker
JFP2
•
