2-11
Hardware Setup
Audio Port Connectors
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
Green audio jack - Line Out, is a connector for speakers or headphones.
Blue audio jack - Line In, is used for external CD player, tapeplayer or
other audio devices.
Pink audio jack - Mic In, is a connector for microphones.
Orange audio jack - Center/ Subwoofer Out in 5.1/ 7.1 channel mode.
Black audio jack - Rear-Surround Out in 4/ 5.1/ 7.1 channel mode.
Gray audio jack - Side-Surround Out in 7.1 channel mode.
