MSI A68HM-E33 V2 Series User Manual

Русский
101


.
1.MIC L
3.MIC R
10.Head
Phone Detection
5.Head Phone
R
7.SENSE_SEN
D
9.Head Phone
L
8.No Pin
6.MIC Detection
4.NC
2
.Ground








 http://youtu.be/DPELIdVNZUI
3.Speaker
4.VCC5
1.Speaker
2.VCC5
1.+
3.-
10.No Pin
5.-
Reset S
witch
HDD LE
D
P
ower Switch
P
ower LED
7.+
9.Reserved
8.-
6.+
4.-
2.+
JFP1
JFP2

 



 
.

MSI A68HM-E33 V2 Series Specifications

General

Chipset	AMD A68H
CPU Socket	FM2+
Memory Support	DDR3
Memory Slots	2
Max Memory	32GB
Form Factor	Micro ATX
PCIe x16 Slots	1
PCIe x1 Slots	1
SATA Ports	4 x SATA 6Gb/s
Audio	Realtek ALC887
RAID Support	RAID 0, 1, 10
Memory Standard	DDR3 1600/1333 MHz
USB Ports	2 x USB 3.0
Audio Channels	7.1 Channel
LAN	Realtek RTL8111G
