MSI A68HM-E33 V2 Series User Manual

Русский
102




1
.
V
C
C
3
.
U
S
B
0
-
1
0
.
NC
5
.
U
S
B
0
+
7
.
G
r
o
u
n
d
9
.
N
o
P
i
n
8
.
G
r
o
u
n
d
6
.
U
S
B
1
+
4
.
U
S
B
1
-
2
.
V
C
C






10.No Pin
14.Ground
8.5V Power
12.Ground
6.Serial IRQ
4.3.3V Power
2.3V Standby power
1.LPC Clock
3.LPC Reset
5.LPC address & data pin0
7.LPC address & data pin1
9.LPC address & data pin2
11.LPC address & data p
in3
13.LPC Frame

MSI A68HM-E33 V2 Series Specifications

General

Chipset	AMD A68H
CPU Socket	FM2+
Memory Support	DDR3
Memory Slots	2
Max Memory	32GB
Form Factor	Micro ATX
PCIe x16 Slots	1
PCIe x1 Slots	1
SATA Ports	4 x SATA 6Gb/s
Audio	Realtek ALC887
RAID Support	RAID 0, 1, 10
Memory Standard	DDR3 1600/1333 MHz
USB Ports	2 x USB 3.0
Audio Channels	7.1 Channel
LAN	Realtek RTL8111G
