MSI A75MA-P35 series User Manual

1-8
Gettng Started
Back Panel Quck Gude
Mouse/Keyboard
A PS/2
®
mouse/keyboard DIN connector for a PS/2
®
mouse/keyboard.
USB 2.0 Port
The USB 2.0 port s for attachng USB 2.0 devces such as keyboard, mouse, or other
USB 2.0-compatble devces.
USB 3.0 Port (optonal)
USB 3.0 port s backward-compatble wth USB 2.0 devces. It supports data transfer
rate up to 5 Gbt/s (SuperSpeed).
Important
In order to use USB 3.0 devces, you must connect to a USB 3.0 port. If a USB cable s
used, t must be USB 3.0 complant.
LAN
The standard RJ-45 LAN jack s for connectng to a
Local Area Network (LAN).
LED Color LED State Condton
Left Yellow O󰘯 LAN l
nk s not establshed.
On(Steady) LAN l
nk s establshed.
On(󰘱ashng) The computer s communcatng wth another computer on the
network.
R
ght Green O󰘯 10 Mb
ts/sec data rate
On 100 Mb
ts/sec data rate
Orange On 1000 Mb
ts/sec data rate
▶
▶
▶
▶
LAN
Keyboard
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
USB 2.0 Port USB 3.0 Port
(optonal)
VGA Port
DVI-D Port
Yellow Green/ Orange
USB 2.0 Port
Mouse
