MSI A75MA-P35 series User Manual

1-21
MS-7697
Chapter 1
Front Panel Connectors: JFP1, JFP2
These connectors connect to the front panel swtches and LEDs. The JFP1 connector
s complant wth the Intel
®
Front Panel I/O Connectvty Desgn Gude. When nstallng
the front panel connectors, please use the enclosed mConnectors to smplfy nstalla-
ton. Plug all the wres from the computer case nto the mConnectors and then plug the
mConnectors nto the manboard.
1.+
3.-
10.No Pin
5.-
Reset Switch
HDD LED
Power Switch
Power LED
7.+
9.Reserved
8.-
6.+
4.-
2.+
JFP1
1.Ground
3.Suspend LED
5.Power LED
7.No Pin
8.+
6.-
4.+
2.-
Buzzer
Speaker
JFP2
Important
On the connectors comng from the case, pns marked by small trangles are postve
wres. Please use the dagrams above and the wrtng on the mConnectors to deter-
mne correct connector orentaton and placement.
The majorty of the computer case’s front panel connectors wll prmarly be plugged
nto JFP1.
Front Panel Audo Connector: JAUD1
Ths connector allows you to connect the front audo panel located on your computer
case. Ths connector s complant wth the Intel
®
Front Panel I/O Connectvty Desgn
Gude.
1.MIC L
3.MIC R
10.Head Phone Detection
5.Head Phone R
7.SENSE_SEND
9.Head Phone L
8.No Pin
6.MIC Detection
4.NC
2.Ground
•
•
