Mining System Installation Guide
Installing Multiple Graphics Cards
You need to prepare PCIe x16 to PCIe x1 Riser Kits to install multiple graphics cards
for mining system and connect as shown below.
Connect PCIe power cables
from PSU to graphics cards
and PCIe x16 risers power
jacks.
Install graphics cards on PCIe x16
risers.
Install one graphics card in PCIe x16 slot of the motherboard or you
can also install the graphics card with PCIe Riser Kit.
Connect PCIe x1 risers and PCIe x16 risers with
USB 3.1 Gen1 cables.
Install PCIe x1 risers into PCIe x1 slots.
Important
Make sure the graphics cards are locked by the latch at the end of the PCIe x16 slots.
