MSI B360-F PRO User Manual

6
Specifications
Continued from previous page
Back Panel
Connectors
y 4x Debug LEDs
y 1x PS/2 keyboard/ mouse combo port
y 1x DVI-D port
y 1x HDMI port
y 2x USB 3.1 Gen1 Type-A ports
y 1x LAN (RJ45) port
y 4x USB 2.0 Type-A ports
y 3x Audio jacks
Internal Connectors
y 1x 24-pin ATX main power connector
y 1x 8-pin ATX 12V power connector
y 3x 4-pin PCIe power connectors （B360-F PRO）/ 2x 4-pin
PCIe power connectors （H310-F PRO）
y 4x 2-pin PS_ON connectors
y 4x SATA 6Gb/s connectors
y 1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1
Gen1 ports)
y 1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
y 1x 4-pin CPU fan connector
y 1x 4-pin system fan connector
y 1x Front panel audio connector
y 2x Front panel connectors
y 1x TPM module connector
y 1x Chassis Intrusion connector
y 1x Serial port connector
y 1x Clear CMOS jumper
y 1x Power button
y 1x Reset button
y 1x Clear CMOS button
I/O Controller NUVOTON NCT5567 Controller Chip
Hardware Monitor
y CPU/System temperature detection
y CPU/System fan speed detection
y CPU/System fan speed control
Continued on next page

MSI B360-F PRO Specifications

General

Brand	MSI
Model	B360-F PRO
Category	Motherboard
Language	English
