9
Block Diagram
Block Diagram
2 Channel DDR4 Memory
USB 3.1 Gen1
PCI_E1
PCI_E2~6
PCI_E7~13
USB 2.0
P/S2 Mouse / Keyboard
Audio Jacks
DMI 3.0
B360/ H310
CPU
NV5567
Super I/O
ASM1187E
Realtek
ALC887
PCIe x16
HDMI
PCI_E14~18
(B360 only)
DVI-D
SATA 6Gb/s
