23
Overview of Components
JCI1: Chassis Intrusion Connector
This connector allows you to connect the chassis intrusion switch cable.
BAT1
Normal
(default)
Trigger the chassis
intrusion event
Using chassis intrusion detector
1. JCI1 connector to the chassis intrusion switch/ sensor on the chassis.
2. 
3. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
4. Set Chassis Intrusion to Enabled.
5. Press F10 to save and exit and then press the Enter key to select Yes.
6. 
screen when the computer is turned on.
Resetting the chassis intrusion warning
1. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
2. Set Chassis Intrusion to Reset.
3. Press F10 to save and exit and then press the Enter key to select Yes.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI B450 TOMAHAWK MAX II and is the answer not in the manual?

MSI B450 TOMAHAWK MAX II Specifications

General IconGeneral
ChipsetAMD B450
CPU SocketAM4
Form FactorATX
Memory Slots4 x DIMM
Maximum Memory128 GB
LANRealtek 8111H Gigabit LAN
RAID SupportRAID 0, 1, 10
PCIe Slots1 x PCIe 3.0 x16, 1 x PCIe 2.0 x16, 3 x PCIe 2.0 x1
Storage6 x SATA 6Gb/s, 1 x M.2
USB Ports6 x USB 2.0
AudioRealtek ALC892
Multi-GPU SupportAMD CrossFire
Memory SpeedDDR4-4133 (OC)
