10
Please install the memory module into the DIMM slot as shown below.
Due to chipset resource usage, the available capacity of memory will be a little less
than the amount of installed.
-
gested to protect the processor.
of memory modules may operate lower than the marked value under the default
state. Please refer www.msi.com for more information on compatible memory.
unplug the power supply power cable from the power outlet. Read the expansion
card’s documentation to check for any necessary additional hardware or software
changes.
If you install a large and heavy graphics card, you need to use a tool such as MSI
Gaming Series Graphics Card Bolster to support its weight to prevent deformation
of the slot.
Processors
Slots
1st, 2nd
and 3rd
Gen AMD
Ryzen
TM
Ryzen™ with Radeon™ Vega
Graphics,
2nd Gen AMD Ryzen™ with
Radeon™ Graphics,
A-series,
Athlon
TM
X4
Athlon™ with
Radeon™
Vega Graphics
PCI_E1 PCIe 3.0 x16 PCIe 3.0 x8 PCIe 3.0 x4
PCI_E2 PCIe 2.0 x1 PCIe 2.0 x1 PCIe 2.0 x1
1
1
2
3
3
2
