11
unplug the power supply power cable from the power outlet. Read the expansion
card’s documentation to check for any necessary additional hardware or software
changes.
If you install a large and heavy graphics card, you need to use a tool such as
to support its weight to prevent deformation
of the slot.
BAT1
: PCIe 3.0 x16 slot (CPU)
: PCIe 3.0 x1 slot (PCH)
Please install the Wi-Fi module into M.2_2 slot as shown below.
Supplied
M.2 screw
1
2
3
