15
Specifications
CPU
Supports 12th/ 13th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors*
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B760 Chipset
Memory
2x DDR4 memory slots, supporting up to 64GB*
Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
• 1DPC 1R Max speed up to 4800+ MHz
• 1DPC 2R Max speed up to 4600+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
1x PCIe 4.0 x16 slot (From CPU)
1x PCIe 4.0 x1 slot (From B760 Chipset)
Onboard Graphics
1x HDMI™ 2.1 port with HDR, supporting a maximum
resolution of 4K 60Hz*/**
1x DisplayPort 1.4 port with HBR2, supporting a maximum
resolution of 4K 60Hz*/ **
1x VGA port, supporting a maximum resolution of
2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*/**
* Available for the processor with integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports 4x SATA 6Gb/s ports (From B760 chipset)
M.2 SSD Slot
2x M.2 slots (Key M)
• M2_1 slot (From CPU)
• Supports up to PCIe 4.0 x4
• Supports 2242/ 2260/ 2280 storage devices
• M2_2 slot* (From B760 chipset)
• Supports up to PCIe 4.0 x4
• Supports up to SATA 6Gb/s
• Supports 2242/ 2260/ 2280 storage devices
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
Continued on next column
