CX61/CR61 (MS-16GB)Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.7：Remove the LVDS, speaker and MIC cable.
6.8：Remove the power cable as pic shows.
6.9：Remove the 2 screws (M2.5*5mm). then
remove the upper case.
Attention: the screw driver torque is 2.0-2.5Kgf-cm
Component P/N Qty
Screw E43-1255001-G68 2
