MSI CX70 - Disconnect Speaker and MIC Cables; Disconnect LVDS and Power Cables; Remove Upper Case

CX70/CR70 (MS-1755) Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.7：Remove the speaker and MIC cable.
6.8：Remove the LVDS and power cable as pic
shows.
6.9：Remove the 2 screws (M2.5*5.5mm). then
remove the upper case.
Attention: the screw driver torque is 2.0-2.5Kgf-cm
Component P/N Qty
Screw E43-1255501-H29 2
MIC
Speaker
Speaker
Power
LVDS
