MSI CX70 - Remove Right I;O Board; Remove Left LCD Hinge Screws; Remove Right LCD Hinge Screws

CX70/CR70 (MS-1755) Disassembly Guide
7、LOWER CASE ASSY
7.4：Remove the Bluetooth cable and 1 screw
(M2.5*4.5mm); then remove the Right I/O board.
Attention: the screw driver torque is: 2.0-2.5Kgf-cm
Component P/N Qty
Right I/O board 607-1755A-01S 1
Screw E43-1254503-G68 1
7.5 ：Remove the 2 screws (M2.5*5.5mm) that
stabilize the left LCD hinge.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255501-H29 2
7.6：：Remove the 2screws (M2.5*5.5mm) that
stabilize the right LCD hinge.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255501-H29 2
