Rear I/O Panel

Component Contents

Component Page

CPU Socket 13

Memory 15

DIMMA1~2, DIMMB1~2: DDR5 DIMM Slots 15

Storage 17

SATA5_6, SATA1~4: SATA 3.0 6Gb/s Ports 17

M2_1~2: M.2 Slots (M Key, PCIe 4.0, 22110/ 2280) 18

Expansion Slots 19

PCIE_1~2: PCIe Expansion Slots 19

Connectors 20

Power Connectors 20

JATX12V1: 12PIN ATX Power Connector 20

ATX4PIN1: 4PIN ATX Power Connector 20

SATAPWR1: SATA Power Connector 21

JSDOMPWR1: SATA DOM Power Connector 21

Cooling Connectors 22

FAN1~8, PUMP1: Fan Power Connectors 22

Other Connectors 23

JFP1: Front Panel Connector 23

JTPM1: SPI TPM Module Box Header 24

JGPIO1: GPIO Header 25

JPMBUS1: PMBUS Box Header 25

JCHASSIS: Chassis Intrusion Header 26

JIPMB1: IPMB Box Header 26

JUSB1: USB 3.2 Port Box Header 27

JUSB2: USB 3.2 Gen 1 Type-A Connector (USB 3.2 Gen 1/ USB 2.0) 27

FP_I2C_1, RBP_I2C_1~2: I2C Box Headers 28

JCOM1: COM Port Box Header 28

Jumpers 29

Onboard LEDs 30

BMC_LED1: BMC Heartbeat LED 30

LED_H1, LED_L1: Port 80 Debug LEDs 30
