Specifications
Specifications
Model MS-S3261
Form factor Micro-ATX
Dimensions 243.84mm (9.6”) x 243.84mm (9.6”)
Processor ∙ 1 x AMD® Ryzen™ 7000 Series Processor, TDP up to 170W
- Processor socket AM5
Chipset AMD B-Class Chipset
Memory ∙ 4 x DDR5 memory slots, supporting up to 128GB
- Supports UDIMM 5200MT/s (2DPC), ECC/ non-ECC
Networking ∙ 4 x GbE RJ45 ports
- Intel® Ethernet controller I210-AT
- JLANCONN1 (L) support shared NIC
Server
Management
∙ Aspeed AST2600 IPMI 2.0 with iKVM support
∙ 1 x GbE RJ45 port for Mgmt. (Realtek® RTL8211FD-CG HF)
Storage ∙ 6 x SATA 3.0 ports (w/ 1 x VCC)
∙ 2 x M.2 M-Key (PCIe 4.0, 22110/ 2280)
- Option 1: PCIe 4.0 x4x0
- Option 2: PCIe 4.0 x2x2
Internal I/O ∙ 1 x Front panel connector
∙ 1 x Chassis intrusion header
∙ 1 x USB 3.2 Gen 1 Type-A connector (USB 3.2 Gen 1/ USB 2.0)
∙ 1 x USB 3.2 port box connector
∙ 2 x SPI TPM module box headers
∙ 1 x GPIO connector
∙ 3 x I2C box headers
∙ 1 x IPMB box header
∙ 1x PMbus box header
∙ 1 x COM port box header
