2-8
BIOS Setup
Devce Mode
Select the devce mode for the parallel port.
Hardware Montor
Press <Enter> to enter the sub-menu.
CPU Smart Fan Target
Controls CPU fan speed automatcally dependng on the current temperature and
to keep t wth a specc range. If the current CPU temperature reaches the target
value, the smart fan functon wll be actvated.
SYS Fan1 Control
Ths tem allows users to select how percentage of speed for the SYSFAN1.
CPU/ System Temperature, CPU FAN/ SYS FAN 1 Speed
These tems show the current status of all of the montored hardware devces/ com
-
ponents such as CPU temperature/ system temperature and all fans’ speeds.
Power Management Setup
Press <Enter> to enter the sub-menu.
EuP 2013
Energy Usng Products Lot 6 2013 (EUP) reduces power consumpton when system
s o or n standby mode.
Note: When enabled, the system wll not support RTC wake up event functons.
Restore after AC Power Loss
Ths tem speces whether your system wll reboot after a power falure or nterrupt
occurs. Settngs are:
[Power O] Always leaves the computer n the power o state.
[Power On] Always leaves the computer n the power on state.
[Last State] Restore the system to the status before power falure or nterrupt
occurred.
Wake Up Event Setup
Press <Enter> to enter the sub-menu.
Wake Up Event By
Settng to [BIOS] actvates the followng elds, and use the followng elds to set the
wake up events. Settng to [OS], the wake up events wll be dened by OS.
Resume By RTC Alarm
The eld s used to enable or dsable the feature of bootng up the system on a
scheduled tme/date.
Date/ HH:MM:SS
If Resume By RTC Alarm s set to [Enabled], the system wll automatcally resume
(boot up) on a specc date/hour/mnute/second speced n these elds (usng the
<+> and <-> to select the date & tme settngs).
Resume By PCI or PCI-E Devce
When set to [Enabled], the feature allows your system to be awakened from the
power savng modes through any event on PCI or PCIe devce.
Resume From S3 by USB Devce
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
To Next Page
