1-9

MS-7721

Chapter 1

VGA Port

The DB15-pn female connector s provded for montor.

DVI-D Port

The DVI-D (Dgtal Vsual Interface- Dgtal) connector can be connected to a LCD mon

tor, or a CRT montor wth an adapter. To connect a montor, please refer to the mon-

tor’s manual for more nformaton.

HDMI Port

The Hgh-De󰘰nton Multmeda Interface (HDMI) s an all-dgtal audo-vdeo nterface

that s capable of transmttng uncompressed streams. HDMI supports all types of TV

formats, ncludng standard, enhanced, or hgh-de󰘰nton vdeo, plus mult-channel

dgtal audo on a sngle cable.

Important

Ths platform supports dual-dsplay functon (HDMI+VGA, HDMI+DVI, VGA+DVI) and

trple-dsplay functon (HDMI+VGA+DVI).

HDMI+VGA HDMI+DVI VGA+DVI HDMI+VGA+DVI

Extend mode

(Extend the desktop to the second montor)

◯ ◯ ◯ ◯

Clone mode

(Two montors have the same screen)

◯ ◯ ◯ ◯

Audo Ports

These connectors are used for audo devces. The color of the jack refers to the functon

of the connector.

Blue-Lne n: Used for connectng external audo outputtng devces.

Green- Lne out: Used as a connector for speakers or headphone.

Pnk- Mc: Used as a connector for a mcrophone.

Black- RS-Out: Rear surround sound lne out n 4/ 5.1/ 7.1 channel mode.

Orange- CS-Out: Center/ subwoofer lne out n 5.1/ 7.1 channel mode.

Gray- SS-Out: Sde surround sound lne out n 7.1 channel mode.

▶

■

MSI FM2-A85XMA-E35 Series User Manual
