Gettng Started
Back Panel Quck Gude
Mouse/Keyboard
A combnaton PS/2
®
mouse/keyboard DIN connector for a PS/2
®
mouse/keyboard.
USB 2.0 Port
The USB 2.0 port s for attachng USB 2.0 devces such as keyboard, mouse, or other
USB 2.0-compatble devces.
USB 3.0 Port (FM2-A85XMA-E35/ FM2-A75MA-E35)
USB 3.0 port s backward-compatble wth USB 2.0 devces. It supports data transfer
rate up to 5 Gbt/s (SuperSpeed).
Important
In order to use USB 3.0 devces, you must connect to a USB 3.0 port. If a USB cable s
used, t must be USB 3.0 complant.
LAN
The standard RJ-45 LAN jack s for connectng to a
Local Area Network (LAN).
LED Color LED State Condton
Left Yellow O󰘯 LAN lnk s not establshed.
On(Steady) LAN lnk s establshed.
On(󰘱ashng) The computer s communcatng wth another computer on the
network.
Rght
Green O󰘯 10 Mbts/sec data rate
On 100 Mbts/sec data rate
Orange On 1000 Mbts/sec data rate
▶
▶
▶
▶
LAN
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
USB 2.0 Port
USB 3.0 Port
(FM2-A85XMA-E35/
FM2-A75MA-E35)
USB 2.0 Port
(FM2-A55M-E35)
VGA Port
DVI-D Port
Yellow Green/ Orange
USB 2.0 Port
Mouse/Keyboard
HDMI Port USB 2.0 Port
