1-27
MS-7721
Chapter 1
JBAT1: Clear CMOS Jumper
There s CMOS RAM onboard that s external powered from a battery located on the
manboard to save system conguraton data. Wth the CMOS RAM, the system can
automatcally boot nto the operatng system (OS) every tme t s turned on. If you want
to clear the system conguraton, set the jumpers to clear the CMOS RAM.
Keep Data Clear Data
1 1
Important
You can clear the CMOS RAM by shortng ths jumper whle the system s o. After-
wards, open the jumper . Do not clear the CMOS RAM whle the system s on because
t wll damage the manboard.
