4. HDMI Connector
HDMI (High Definition Multimedia Interface) is a new interface standard for PCs, displays and
consumer electronics devices that supports standard, enhanced and high-definition video, plus
multi-channel digital audio on a single cable.
5. USB Port
The USB port allows you to connect USB-interface peripheral devices, such as the mouse,
keyboard, modem, portable hard disk module, printer and more.
6. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported. Connect your
speakers to the proper connectors as shown below.
Mic In/Line In: Used for an external microphone.
Headphone out/ SPDIF-out: Used for speakers or
headphones. The S/PDIF connector is also provided for
digital audio transmission to external speakers through an
optical fiber cable.
