18
Specifications
* Based on CIE1976 test standards.
Model G242C
VESA Mounting
∙ Plate Type: 75x 75 mm
∙ Screw Type: M4 x 10 mm
•Thread Diameter: 4 mm
•Thread Pitch: 0.7 mm
•Thread Length: 10 mm
Dimension (W x H x D) 537.4 x 414.7 x 215.6 mm
Weight 3.3 Kg (net)/ 5.15 Kg (gross)
Environment
Operating
∙ Temperature:0℃to40℃
∙ Humidity: 20% to 90%, non-condensing
∙ Altitude: 0 ~ 5000m
Storage
∙ Temperature:-20℃to60℃
∙ Humidity: 10% to 90%, non-condensing
