GE40/CR42 (MS-1492) Disassemble Guide
■ 6、LOWER CASE ASSY
6.7:Remove the left Power cable.
6.8:Remove the Hall Switch cable.
6.9:Remove the Power board.
Component
P/N
Qty
Power board
607-1492B-01S
1
