User's Manual
2-8 2-9
5. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
6. RJ-45 Connector
The Ethernet connector, with optionally supported transmitting rate of
10/100/1000/10000 megabits per second, is used to connect a LAN cable for network
connection.
7. Mini-DisplayPort
The Mini-DisplayPort is a miniaturized version of the DisplayPort, with a suitable
adapter, the Mini-DisplayPort may be used to drive displays with a VGA, DVI or HDMI
interface.
8. USB 3.1 Port (Type C)
USB 3.1, the SuperSpeed+ USB, delivers the higher interface speeds for connecting
various devices, such as storage devices, hard drives, or video cameras, and offers
more advantages over high-speed data transferring.
The slim and sleek USB Type C connector features reversible plug orientation and
cable direction, and supports scalable performance to future-proof solution, including
USB 3.x, DisplayPort, PCIe, Audio, and Thunderbolt 3 (Optional).
