SATA1~4: SATA 6Gb/s 󳰛󱿂
󸴐󱛩󳰚󱿂󴂞 SATA 6Gb/s 󵬓󹪸󳰚󱿂󴪇󱙂󳰚󱿂󱿔󱝥󸴗󳰚󱘈󱙂 SATA 󸚤󲠫
SATA1
SATA2
SATA3
SATA4
󴱅󳞲
y 󸛝󱹂󲺽 SATA 󳽉󳮹󶳢󲺧󳩵󳦎 90 󳍿󲀥󱳎󽘜󱞼󸱶󸳣󶌱󱙆󱿔󷃫󱞵󱲡󵡂󳽉󳮹󱘸󲢀
y SATA 󶳢󵵙󱘺󶔏󴈄󵸒󱿻󵵙󳱤󱿂󽘜󵏍󶻽󽘜󱙚󱛌󷐽󵸢󶐀󹠣󳐫󸚔󸴗󳰚󳧡󳌣󳰚󱿂󶔏󲔩󱙛󴋄󱘔
JFP1, JFP2: 󱴚󶷉󹪸󴋃󳰛󱿂
󸴐󱛩󳰚󱿂󸴗󳰚󱴙󶷉󹪸󴋄󱘔󵵙󳐴󱯃󲃅 LED 󵉈
1
2 10
9
JFP1
1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
1
JFP2
1 Speaker - 2 Buzzer +
3 Buzzer - 4 Speaker +
HDD LED
RESET SW
HDD LED
HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
JFP1

MSI H310M PRO-M2 Specifications

General

Form Factor	Micro-ATX
Chipset	Intel H310
CPU Socket	LGA 1151
Memory Slots	2
Memory Type	DDR4
Maximum Memory	32 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	4 x USB 3.1 Gen 1, 6 x USB 2.0
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
Storage Interface	4 x SATA 6Gb/s
Memory Speed	2666/ 2400/ 2133 MHz
Video Outputs	1 x VGA
