MSI H510I PRO WIFI - Internal Connectivity; SATA and M.2 Slots

13
 
30º30º

These connectors are SATA 6Gb/s interface ports. Each connector can connect to one
SATA device.
SATA1
SATA2
SATA3
SATA4


 Please do not fold the SATA cable at a 90-degree angle. Data loss may result
during transmission otherwise.
 SATA cables have identical plugs on either sides of the cable. However, it is

saving purposes.

Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below.
