MSI H510I PRO WIFI User Manual

17
 

This connector allows you to connect the chassis intrusion switch cable.
Normal
(default)
Trigger the chassis
intrusion event

 Connect the  connector to the chassis intrusion switch/ sensor on the
chassis.
 Close the chassis cover.
 Go to .
 Set  to .
 Press F10 to save and exit and then press the  key to select .
 Once the chassis cover is opened again, a warning message will be displayed on
screen when the computer is turned on.

 Go to .
 Set  to Reset.
 Press to save and exit and then press the  key to select .

MSI H510I PRO WIFI Specifications

General

Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel H510
Audio output channels	8 channels
Motherboard form factor	mini ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10 x64
DirectX version	12.0
Parallel processing technology support	-
DisplayPort version	1.4
USB 2.0 ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
TPM connector	Yes
LAN controller	Realtek RTL8125B
Bluetooth version	5.1
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet interface type	2.5 Gigabit Ethernet
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 2933, 3000, 3200 MHz
Supported memory clock speed (max)	3200 MHz
Processor socket	LGA 1200 (Socket H5)
Compatible processor series	Intel Celeron, Intel Core i9, Intel Pentium Gold
