MSI H510M PRO

7
 

 
Off No link
Yellow Linked
Blinking Data activity

 
Off 10 Mbps connection
Green 100/1000 Mbps connection
Orange 1 Gbps connection


To configure 7.1-channel audio, you have to connect front audio I/O module to JAUD1
connector and follow the below steps.
 Click on the  to open the dialog
below.
 Select .
 Plug your speakers to audio jacks on rear and front I/O panel. When you plug into
a device at an audio jack, a dialogue window will pop up asking you which device
is current connected.

PS/2 Mouse/
Keyboard
LAN
USB 2.0 Type-A
USB 3.2 Gen 1
5Gbps Type-A
DisplayPort(For
H510M PRO)
VGA Port (For H510M
PRO/ H510M-A PRO/
H510M BOMBER/ B560M
PRO-E/ B560M-X)
USB 2.0 Type-A
Line-in
Line-out
MIC
