The pump CG are shown in the previous drawings. Use only properly rated lifting harnesses for installation,
removal, and maintenance of the MSI Hybrid™ Well Service Pump. Please note that the weights listed on the
following pages are average weights based on typical pump configurations. Please contact MSI for
configuration-specific weights.
Safe lifting methods are shown below:
To lift complete pump, use rated swivel
lifting eyes threaded into the 3/4-10 UNC
holes at locations shown.
TIH-600 Pump Total Wt ~ 4700 LBS
QIH-1000/1300 Pump Total Wt ~ 7500 LBS
