SECTION 8 SPARE PARTS LIST, EXPENDABLES
8.1 Recommended Spare Parts List
MSI recommends that at a minimum the following spare parts be available during pump operation. See
Section 9 for size specific part numbers. Contact MSI for availability of expendables packages for all
plunger sizes.
8.2 Fluid End Parts
Item
Triplex Quantity
Quintuplex Quantity
Fluid End Plunger
1
2
Lantern Ring
3
5
Packing Nut
1
2
Packing Set
3
5
O-Ring, Stuffing Box – Fluid End Side
3
5
Back-Up, Stuffing Box – Fluid End Side
3
5
O-Ring, Stuffing Box – Nut Side
3
5
Back-Up, Stuffing Box – Nut Side
3
5
O-Ring, Packing Nut
6
10
Seal, Discharge Cover
3
5
Seal, Suction Cover
3
5
Stuffing Box Adapter
3
5
Valve or Valve Insert
3
5
Valve Spring
3
5
Valve Stop
3
5
8.3 Power End Parts
Item
Triplex Quantity
Quintuplex Quantity
Power End Plunger Seal
3
5
O-Ring, Suction Manifold
3
5
Gasket, Power End Plunger Seal Housing
3
5
