MSI Hybrid Triplex - Page 60

3
2
GROOVE CONNECTIONS
STANDARD CUT
VICTAULIC
®
1
NPS 4 = 4"
NPS 5 = 4.5"
NPS 6 = 5"
NPS 4, 5, OR 6 STD
NOTE:
MANIFOLD SHOWN IS TYPICAL, OTHER SIZES AND CONFIGURATIONS
ARE AVAILABLE, CONTACT MSI SALES FOR OPTIONS.
ITEM NO. DESCRIPTION PART NUMBER
1 SUCTION MANIFOLD SEE NOTE
2 SUCTION MANIFOLD BOLT HC0108
3 SUCTION MANIFOLD O-RING OC0079
