Using 4- or 6-Channel Audio Function
1 Line Out (Front channels)
2 * Line Out (Rear channels)
3 * Line Out (Center and
Subwoofer channel)
* Both Line In and MIC function are converted to Line Out function when 4-
Channel Mode for 6-Speaker Output is selected.
6-Channel Mode for 6-Speaker Output
Refer to the following diagram and caption for the founction of each
jack on the back panel when 6-Channel Mode is selected.
2
3
1
