3-25
BIOS Setup
IR Pin Select
Set to IRRX/IRTX when using an internal IR module connected to the IR
header. Set to SINB/SOUTB. when connecting an IR adapter to COM B.
Parallel Port
This field specifies the base I/O port address of the onboard parallel port.
Selecting Auto allows AMIBIOS to automatically determine the correct base
I/O port address. Settings: Auto, 378, 278, Disabled.
Port Mode
This item selects the operation mode for the onboard parallel port: ECP,
Normal, Bi-Dir or EPP.
EPP Version
The item selects the EPP version used by the parallel port if the port is set
to EPP mode. Settings: 1.7, 1.9.
Port IRQ
When OnBoard Parallel Port is set to Auto, the item shows Auto indicat-
ing that BIOS determines the IRQ for the parallel port automatically.
Port DMA
This feature needs to be configured only when Parallel Port Mode is set
to the ECP mode. When Parallel Port is set to Auto, the field will show
Auto indicating that BIOS automatically determines the DMA channel
for the parallel port.
OnChip IDE Controller
This setting controls the onboard IDE controller. Setting options: Disabled,
Primary, Secondary, Both.
OnBoard LAN
This setting controls the onboard LAN controller. Setting options: Disabled,
Enabled.
OnBoard LAN P.M.E.
This feature allows the onboard LAN to be awakened from the power
saving modes through any event on PME (Power Management Event).
Setting options: Disabled, Enabled.
