MSI MAG B460 TOMAHAWK User Manual

25
Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1, PUMP_FAN1,
SYS_FAN1~6
Fan Connectors 35
CPU_PWR1, ATX_PWR1 Power Connectors 32
CPU Socket LGA 1200 socket 26
DIMMA1, DIMMA2, DIMMB1,
DIMMB2
DIMM Slots 27
JAUD1 Front Audio Connector 31
JBAT1 Clear CMOS (Reset BIOS) Jumper 37
JCI1 Chassis Intrusion Connector 36
JFP1, JFP2 Front Panel Connectors 31
JRAINBOW1~2 Addressable RGB LED connectors 40
JRGB1~2 RGB LED connector 39
JTPM1 TPM Module Connector 34
JUSB1 USB 3.2 Gen 1 5Gbps Type-C Connector 33
JUSB2 USB 3.2 Gen 1 5Gbps Connector 33
JUSB3~4 USB 2.0 Connectors 34
LED_SW1 EZ LED Control 38
M2_1~2 M.2 Slots (Key M) 29
PCI_E1~4 PCIe Expansion Slots 28
SATA1~6 SATA 6Gb/s Connectors 28

MSI MAG B460 TOMAHAWK Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium G
Audio chip	Realtek ALC1200
Component for	PC
Motherboard chipset	Intel B460
Audio output channels	7.1 channels
Motherboard form factor	ATX
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2666, 2933 MHz
PCI Express x1 (Gen 3.x) slots	1
PCI Express x16 (Gen 3.x) slots	2
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Wi-Fi	No
LAN controller	Realtek RTL8125B
Ethernet interface type	2.5 Gigabit Ethernet, Gigabit Ethernet
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
BIOS type	UEFI AMI
ACPI version	6.2
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	3.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel processing technology support	-

Weight and Dimensions

Depth	244 mm
Width	305 mm
