6. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
30º30º
M.2 standoff
heatsink standoff
3
5
4
M.2 screw
6
6
3.
or remove the M.2 standoff if your M.2 SSD length is same as the length of M.2
heatsink to avoid damage to the M.2 SSD.
4. Insert your M.2 SSD into the M.2 slot at a 30-degree angle.
5.
M.2 standoff in step 3.
To Next Page
