Overview
1-91-8
11
USB 3.2 Gen 2 Port
USB 3�2 Gen 2, the SuperSpeed USB 10Gbps, delivers high-speed data
transfer for various devices, such as storage devices, hard drives, video
cameras, etc�
12
USB 3.2 Gen 2 Port (Type-C)
USB 3�2 Gen 2, the SuperSpeed USB, delivers the higher interface speeds
for connecting various devices, such as storage devices, hard drives,
or video cameras, and oers more advantages over high-speed data
transferring� The slim and sleek USB Type C connector features reversible
plug orientation�
13
LAN Jack
The standard RJ-45 LAN jack is provided for connection to the Local Area
Network (LAN)� You can connect a network cable to it�
Green/ OrangeYellow
LED Color LED State Condition
Yellow O LAN link is not established�
On (steady state) LAN link is established�
On (blinking) The computer is communicating with another computer on
the LAN�
Green O 10 Mbit/sec data rate is selected�
On 100 Mbit/sec data rate is selected�
Orange On 1000 Mbit/sec data rate is selected�
14
USB 3.2 Gen 1 Port
15
CS-Out
Center/ subwoofer line out in 5�1/ 7�1 channel mode�
16
RS-Out
Rear surround sound line out in 4/ 5�1/ 7�1 channel mode�
17
S/PDIF-Out
This S/PDIF (Sony & Philips Digital Interconnect Format) connector is
provided for digital audio transmission to external speakers through an
optical ber cable.
