Overview
PB1-10
18
Line-In
This connector is provided for external audio output devices�
19
Line-Out
This connector is provided for headphones or speakers�
20
Mic-In
This connector is provided for microphones�
21
Ventilator
The ventilator on the enclosure is used for air convection and to prevent the
equipment from overheating� Do not cover the ventilator�
22
Power Jack
Power supplied through this jack supplies power to your system�
23
Power Supply Switch
Switch this switch to
I
can turn on the power supply� Switch it to
0
to cut o
the power circulation�
Important
High-speed devices are recommended for USB 3�2 ports whereas low-speed devices,
such as mouse or keyboard, are suggested to be plugged into the USB 2�0 ports�
