Specifications

Continued from previous page

Internal Connectors

∙ 1x 24-pin ATX main power connector

∙ 1x 8-pin ATX 12V power connector

∙ 1x 4-pin ATX 12V power connector

∙ 6x SATA 6Gb/s connectors

∙ 1x USB 3.2 Gen 1 5Gbps Type-C port

∙ 1x USB 3.2 Gen 1 5Gbps connector (support additional 2

USB 3.2 Gen 1 5Gbps ports)

∙ 2x USB 2.0 connectors (support additional 4 USB 2.0 ports)

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin water pump connector

∙ 6x 4-pin system fan connectors

∙ 1x front panel audio connector

∙ 2x system panel connectors

∙ 1x chassis intrusion connector

∙ 1x Clear CMOS jumper

∙ 2x 4-pin RGB LED connectors

∙ 2x 3-pin RAINBOW LED connectors

∙ 1x TPM module connector

∙ 1x TBT connector*

∙ 1x RTD3 connector

*Thunderbolt card need support RTD3

LED Features

∙ 1x LED Control switch

∙ 4x EZ Debug LED

I/O Controller NUVOTON NCT6687 Controller Chip

Hardware Monitor

∙ CPU/System temperature detection

∙ CPU/System fan speed detection

∙ CPU/System fan speed control

Form Factor

∙ ATX Form Factor

∙ 12 in. x 9.6 in. (30.5 cm x 24.4 cm)

BIOS Features

∙ 1x 256 Mb flash

∙ UEFI AMI BIOS

∙ ACPI 6.2, SM BIOS 3.2

∙ Multi-language

Continued on next page

Questions and Answers:

Need help?

Do you have a question about the MSI MAG Z490 TOMAHAWK and is the answer not in the manual?

MSI MAG Z490 TOMAHAWK Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i9
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4200, 4266, 4300, 4400, 4800 MHz
RAID levels	0, 1, 5, 10
Number of HDDs supported	6
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA
DirectX version	12.0
Maximum resolution	4096 x 2304 pixels
Number of displays supported	2
Parallel processing technology support	2-Way CrossFireX
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Intel I219-V, Realtek RTL8125-CG
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC1200
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel Z490
Audio output channels	7.1 channels
Motherboard form factor	ATX
Number of mounting holes	9
Windows operating systems supported	Windows 10
BIOS type	-
Cables included	SATA
Harmonized System (HS) code	84733020
