MSI MAG Z490 TOMAHAWK - Thunderbolt and RTD3 Connectors; Thunderbolt Add-on Card Connector (JTBT1); Intel RTD3 Connector (JRTD3)

37
Overview of Components
JTBT1: Thunderbolt Add-on Card Connector
This connector allows you to connect the add-on Thunderbolt I/O card.
1
1 FORCE_PWR 2 SCI_EVENT
3 SLP_S3# 4 SLP_S5#
5 GND
JRTD3: Intel RTD3 Connector
This connector allows you to connect the RTD3 connector on the add-on Thunderbolt
I/O card that supports RTD3.
1
1 WAKE 2 PWR EN
3 GND
