Overview of Components
3. Please install the supplied EZ M.2 Clip kit in the M.2 slot according to your SSD
length.

Important
Please skip step 3 when installing the 2280 M.2 SSD.
4. 
5. Rotate the EZ M.2 Clip to fix the M.2 SSD.
30º30º
5
4
3
6. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
6
6
6
6
