MSI MEG Z490 UNIFY User Manual

27
Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1, PUMP_FAN1,
SYS_FAN1~6
Fan Connectors 43
CPU_PWR1~3, ATX_PWR1 Power Connectors 36
CPU Socket LGA 1200 CPU Socket 28
DIMM Slots Memory slots 29
JAUD1 Front Audio Connector 40
JBAT1 Clear CMOS (Reset BIOS) Jumper 46
JBLK_U1 Base clock Plus connector 37
JCI1 Chassis Intrusion Connector 45
JCORSAIR1 CORSAIR Connector 49
JFP1, JFP2 Front Panel Connectors 35
JLN1 Low Temperature Booting Jumper 38
JOC_FS1 OC Force Enter BIOS Button 39
JOC_RT1 OC Retry Button 39
JPWRLED1 LED power input 50
JRAINBOW1~2 Addressable RGB LED connectors 48
JRGB1 RGB LED connector 47
JRTD3 Intel RTD3 Connector 44
JSLOW1 Slow Mode Booting Jumper 38
JTBT1 Thunderbolt Add-on Card Connector 44
JTPM1 TPM Module Connector 42
JUSB1 USB 3.2 Gen 2 Type-C Connector 40
JUSB2 USB 3.2 Gen 1 Connector 41
JUSB3~4 USB 2.0 Connectors 42
LED_SW1 EZ LED Control 51
M2_1~3 M.2 Slots (Key M) 32
PCI_E1~5 PCIe Expansion Slots 30
POWER1, RESET1 Power Button, Reset Button 46
SATA1~6 SATA 6Gb/s Connectors 34

MSI MEG Z490 UNIFY Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium G
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2666, 2933 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express 3.0
Parallel processing technology support	2-Way SLI, 3-Way CrossFireX
USB 2.0 connectors	2
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
LAN controller	Realtek RTL8125B
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC1220
Component for	PC
Motherboard chipset	Intel Z490
Audio output channels	7.1 channels
Motherboard form factor	ATX
Number of mounting holes	9
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
