UEFI BIOS

EZ Mode

At EZ mode, it provides the basic system information and allows you to configure the

basic setting. To configure the advanced BIOS settings, please enter the Advanced

Mode by pressing the Setup Mode switch or F7 function key.

XMP Profile

Component

Information

System

information

Boot device

priority bar

Function

buttons

Language

GAME BOOST

Screenshot

Setup Mode switch

M-Flash

Hardware

Monitor

Favorites

∙ GAME BOOST - click on it to toggle the GAME BOOST for overclocking. This function

is only available when both of the motherboard and CPU are supporting this function.

⚠

Important

Please don’t make any changes in OC menu and don’t load defaults to keep the

optimal performance and system stability after activating the GAME BOOST function.

∙ XMP Profile - allows you to select the XMP profile for memory to overclock. This

function is only available when the system, memory and CPU are supporting this

function.

∙ Setup Mode switch - press this tab or the F7 key to switch between Advanced mode

and EZ mode.

∙ Screenshot - click on this tab or the F12 key to take a screenshot and save it to USB

flash drive (FAT/ FAT32 format only).

∙ Search - click on this tab or the Ctrl+F keys to enter the search page. It allows you

to search by BIOS item name. Move the mouse over a blank space and right click the

mouse to exit the search page.

⚠

Important

In search page, only the F6, F10 and F12 function keys are available.

Questions and Answers:

Need help?

Do you have a question about the MSI MEG Z490 UNIFY and is the answer not in the manual?

MSI MEG Z490 UNIFY Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium G
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2666, 2933 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express 3.0
Parallel processing technology support	2-Way SLI, 3-Way CrossFireX
USB 2.0 connectors	2
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
LAN controller	Realtek RTL8125B
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC1220
Component for	PC
Motherboard chipset	Intel Z490
Audio output channels	7.1 channels
Motherboard form factor	ATX
Number of mounting holes	9
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
Harmonized System (HS) code	84733020
