23
Rear Cover & Panel Rear Cover Assembly
1. Place the panel rear cover ❶ on the upper part of the LCD bezel with screw
holes aligned. Tighten the screws ❷ with a cross-head screwdriver to secure
the panel rear cover in place.
2. Place the rear cover
❸ on the lower part of the LCD bezel with screw holes
aligned. Tighten the screws ❹ with a cross-head screwdriver to secure the rear
cover in place.
2
1
4
3
