MSI MPG B650I EDGE WIFI User Manual

21
Connecteurs de panneau arrière
11 7766
88
5522 4433
1010 111199
Élément Description
1 Bouton Clear CMOS
2
Port HDMI™
3 Ports USB 3.2 Gen 1 5Gb/s Type-A (depuis CPU)
4 Ports USB 3.2 Gen 2 10 Gb/s Type-A (depuis CPU)
5 Prise LAN 2,5 Gb/s
6 Connecteurs d’antenne Wi-Fi
7 Prise d’entrée ligne
8
Bouton Flash BIOS - Veuillez vous référer à la page 49 pour la mise à
jour du BIOS avec le bouton Flash BIOS.
9
Port USB 3.2 Gen 2 10 Gb/s Type-A (depuis CPU)
 Port Flash BIOS
10 Port USB 3.2 Gen 2x2 (20 Gb/s) Type-C (depuis chipset B650)
11 Port USB 3.2 Gen 2 10 Gb/s Type-A (depuis chipset B650)
12 Prise de sortie ligne
13 Prise d’entrée microphone
1212 1313

MSI MPG B650I EDGE WIFI Specifications

General

Processor socket	Socket AM5
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 7 7th Gen, AMD Ryzen 9 7th Gen
Non-ECC	Yes
Number of memory slots	2
Supported memory types	DDR5-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	4800, 5000, 5200, 5400, 5600, 5800, 6000, 6200, 6400 MHz
RAID levels	0, 1, 10
Supported storage drive interfaces	M.2, SATA
Parallel processing technology support	-
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
LAN controller	Realtek RTL8125B
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC4080
Component for	PC
Motherboard chipset	AMD B650
PC health monitoring	Fan
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Windows operating systems supported	Windows 10 x64

Weight and Dimensions

Width	170 mm
