MSI MPG B650I EDGE WIFI

33

󴳇󳠴
󲹀󲹤󱹿󱢖󶅚󲹯󱰯󹩙󴽥󸼁󱴺󹩙󴽥
󳲜󶬖󶅚󸓄󱚘
󹩙󴽥
󹩙󴽥󳲜󶬖
CPU_PWR1
 󱥯󲁢󲁿  󱥯󲁢󲁿
1 Ground 2 Ground
3 Ground 4 Ground
5 +12V 6 +12V
7 +12V 8 +12V
ATX_PWR1
 󱥯󲁢󲁿  󱥯󲁢󲁿
1 +3.3V 2 +3.3V
3 Ground 4 +5V
5 Ground 6 +5V
7 Ground 8 PWR OK
9 5VSB 10 +12V
11 +12V 12 +3.3V
13 +3.3V 14 -12V
15 Ground 16 PS-ON#
17 Ground 18 Ground
19 Ground 20 Res
21 +5V 22 +5V
23 +5V 24 Ground
5
4 1
8
CPU_PWR1
24
131
12
ATX_PWR1
