3. Remove the protective films from the thermal pad on the M.2 plate.
33
4. Move and fasten the M.2 standoff screw to the appropriate location for 2260 M.2
SSD. Skip this step if you install 2280 SSD.
44
5. Insert your M.2 SSD into the M2_1 slot at a 30-degree angle.
6. Secure the M.2 SSD in place with the supplied M.2 screw.
30º30º
66
55
