MSI MPG X570 Gaming Edge WIFI User Manual

16
Specifications
Continued from previous page
Wireless LAN &
Bluetooth
®
Intel
®
Dual Band Wireless-AC 3168
 Supports 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz)
up to 433 Mbps
 Supports Dual Mode Bluetooth
®
2.1, 2.1+EDR, 3.0, 4.0,
BLE, 4.2
 The Wireless module is pre-install in the M2_3 (Key-E)
slot
Storage
y 6x SATA 6Gb/s ports
 SATA3~SATA6 ports (from AMD
®
X570 Chipset)
 SATA1~SATA2 ports (from ASMedia ASM1061)
y 2x M.2 slots (Key M)*
 M2_1 slot (from AMD
®
Processor)
 Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
 Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™
with Radeon™ Vega Graphics and 2nd Gen AMD
Ryzen™ with Radeon™ Graphics)
 Supports 2242/ 2260/ 2280/ 22110 storage devices
 M2_2 slot (from AMD
®
X570 Chipset)
 Supports PCIe 3.0 x4 and SATA 6Gb/s
 Supports 2242/ 2260/ 2280 storage devices
RAID
y Supports RAID 0, RAID 1 and RAID 10 for X570 chipset
SATA storage devices
y Support RAID 0, RAID 1 and RAID 10 for M.2 NVME storage
devices
Audio
Realtek
®
ALC1220 Codec
y 7.1-Channel High Definition Audio
y Supports Optical S/PDIF output
Continued on next page

MSI MPG X570 Gaming Edge WIFI Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	1866, 2133, 2400, 2666 MHz
Audio chip	Realtek ALC1220
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Number of mounting holes	9
Motherboard chipset family	AMD
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64
Cables included	SATA
HDMI version	1.4
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Number of SATA III connectors	6
BIOS type	UEFI AMI
LAN controller	Realtek RTL8111H
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way CrossFireX
Processor socket	Socket AM4
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243 mm
Width	304 mm
